Key features
1. Sharp
2. High cutting efficiency, long life
3. High Safety
4. Comply with MPA certification standards
Introduction
OASIS Universal cutting disc is a high-level abrasive product. It can be widely used for cutting metal like Inox, Iron, carbon steel etc. with good performance.
OASIS is a high-level abrasive product brand of China Langfang Shengsen Abrasives Co., Ltd., And OASIS cutting disc are refined by special technology, with good quality, high safety and long life; The products have passed the European MPA certification, implemented EN12314 standards.
Specifications
|
Name |
Universal cutting disc |
|
Main ingredients |
Aluminum oxide |
|
Ingredient type |
White corundum/Brown corundum |
|
Type |
41 Flat Type/42 Depressed Type |
|
Max.WLV (m/s) |
80 |
Model And Parameters
|
Size (mm) |
Abrasive |
T (mm) |
HD (mm) |
MORS (rpm) |
|
75 |
A/WA |
1/1.6/2 |
6.5/9.5/10 |
20400 |
|
107 |
A/WA |
0.8/1/1.2/1.6/2 |
16 |
14200 |
|
115 |
A/WA |
0.8/1/1.2/1.6/2/2.5/3 |
22.23 |
13300 |
|
125 |
A/WA |
0.8/1/1.2/1.6/2/2.5/3 |
22.23 |
13300 |
|
150 |
A/WA |
1.2/1.4/1.6/2/2.5/3 |
22.23 |
10191 |
|
180 |
A/WA |
1.4/1.6/2/2.5/3 |
22.23 |
8500 |
|
230 |
A/WA |
1.6/2/2.5/3 |
22.23 |
6650 |
|
255 |
A/WA |
2.5/3 |
22.23/25.4 |
5995 |
|
305 |
A/WA |
2.5/3/3.5 |
16/19/20/25.4 |
5100 |
|
355 |
A/WA |
2.5/3/3.5 |
16/19/20/22.23/25.4/32 |
4400 |
|
400 |
A/WA |
2.5 |
25.4 |
3850 |
|
405 |
A/WA |
3/3.5/4 |
32 |
3850 |
Advantages
1. [Sharp] Workpieces can be cut easily without jitter of the discs.
2. [Avoid burns] The workpiece to be processed will not be discolored because of burning. There are only a few burrs, minimizing loss and showing high-quality cutting results.
Tips
Before use, please read the user guide carefully and wear special protective gear to ensure safe use.
